Residual current circuit breaker 4P 25A 0,03A, type AC / SR6HM-4P-25 /T2UK

Name: Residual current circuit breaker 4P 25A 0,03A, type AC / SR6HM-4P-25 /T2UK
Brand: Gacia

Gacia

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nResidual current circuit breaker 4P 25A 0,03A, type AC / SR6HM-4P-25 /T2UK\nParameters:\n\n--Degree of protection (IP): IP20\n-- Mounting method: DIN rail\n-- Sensitivity: AC\n-- Rated differential current [A]: 0.03\n-- Frequency: 50/60 Hz\n-- Rated voltage [V]: 400\n-- Number of poles: 4\n-- Rated current [A]: 25\n-- Short-circuit withstand strength (Icw) [kA]: 6\n\nTechnical data: type: AC rated current: 25A rated residual current A: 30mA rated residual current A: 500 trip time: 0.1 s resistance to voltage surge U imp: 6000V short-circuit strength Inc: 6000 pollution degree: 2 voltage rated Ue: 400V rated insulation Ui: 500V current frequency Hz: 50/60 electrical life: 4000 mechanical life: 4000 operating position indicator: yes protection class: IP 20 storage temperature: -30 / + 70 \u00B0 C operating temperature: - 30 / + 50 \u00B0 C maximum cross-section of connection cables: 25 mm2 tightening toS
