Installation Cable H05V-K H05V-K/ LgY 500V LgY_1_never_500V_100

Name: Installation Cable H05V-K H05V-K/ LgY 500V LgY_1_never_500V_100
Brand: TEXSIM

TEXSIM

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nInstallation cable H05V-K (LgY) 1 blue /100 m/\nTEXSIM\nMPN : LgY_1_no_500V_100\nEAN: 5902304302987\nApproximate Outside Diameter: 2,9000\nRated Voltage U: 500\nRated Voltage U0: 300\n\nPrice per 1 ring (100m)\nTechnical parameters\nParametersValue\nLow smoke emission (according to EN 61034-2)No\nLow temperature resistant (according to EN 60811-1-4)No\nOil-resistant (according to EN 60811-2-1)No\nHalogen-free EN 50267-2-2No\nFlame ProofAccording to EN 60332-1-2\nCore InsulationPVC\nColour of insulationBlue\nScreenNo\nCore GradeClass 5 = Flexible\nNominal cross section of core [mm\u00B2]1mm\u00B2\nApproximate Outer Diameter [mm]2,9000mm\nRated voltage U [kV]500 kV\nRated voltage U0 [kV]300 kV\nApproximate Cable Weight [kg/km]13kg/km\nPermissible temperature of the fixed cable [\u00B0C] to70\u00B0C\nPermissible temperature of the fixed cable [\u00B0C] from-40\u00B0C\n\nWeight: 1.3 kg\n\n.
