Current Transformer TP-600-5 TI

Name: Current Transformer TP-600-5 TI
Brand: F&F

F&F

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nCurrent Transformer TP-600-5\nF&F\nMPN : TP-600-5\nEAN: 5902431671956\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nAccuracy Class1\nWith touch protectionNo\nCalibratedYes\n\nProduct Description\n\nThree phase. With a closed core. 600/5 gearbox. Power 2.5VA. The 3-phase (3 in 1) current transformer is used for indirect measurement of three-phase currents. Its design allows mounting directly to the outputs of the circuit breakers (ABB Isomax Series, Merlin Gerin Series NS and analog), saving installation time and space in the switchgear.\n\nOperation The cable with the measured current passes through the main opening of the converter (P1/P2), which corresponds to a primary winding. The second winding terminals S1 and S2 are connected to the terminals of the measuring circuit of the control or measuring device. The amperage ratio in both windings is a constant variable an.
