CKF CKF-316-TRMS Microprocessor Sorting and Expiration Relay

F&F

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nMicroprocessor-based phase sequence and phase loss sensor, DIN rail mount /T2UK\nParameters:\n\n--CN: 85364900\n-- PKWiU: 27.12.24.0\n-- Phase sequence control: Yes\n-- Phase loss control: Yes\n-- Phase unbalance control: Yes\n-- Width [mm]: 18\n\nSupply voltage 3 \u00D7 400 V + N Cooperation with power generators NO Phase loss / asymmetry control YES Phase sequence control YES Contactor contact control NO Actuator relay Maximum load current 10 A Contact configuration 1 \u00D7 NO/NC Contact separation YES Voltage asymmetry of activation 55 V Voltage hysteresis 5 V Switch-off delay 4 s Power control 2 \u00D7 LED Connection 2.5 mm2 screw terminals Tightening torque 0.4 Nm Power consumption 1.6 W Operating temperature -25\u00F740\u00B0C Dimensions 1 module (18 mm) Rail mounting 35mm Degree of protection IP20\n\n(Price for 1 Pcs)\nImportant information!\nPlease read the following information to avoid misuS
