CZF-BR-TRMS phase sequence and phase loss sensor /T2UK

Name: CZF-BR-TRMS phase sequence and phase loss sensor /T2UK
Brand: F&F

F&F

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nCZF-BR-TRMS phase sequence and phase loss sensor /T2UK\nParameters:\n\n--CN: 85364900\n-- PKWiU: 27/12/24.0\n-- Voltage measurement range [V] up to: 400\n-- Width [mm]: 35\n-- Number of changeover contacts: 1\n-- Maximum allowed time delay when power is applied [s]: 8\n-- Phase unbalance control: Yes\n-- Phase loss control: Yes\n-- Phase sequence control: No\n\nWith adjustable voltage unbalance threshold. Contact 1 x NO/NC. Measurement of the actual effective voltage value (TrueRMS) The CZF-BR TrueRMS phase loss sensor is designed to protect an electric motor powered from a three-phase network in cases of voltage loss in at least one phase or voltage asymmetry between the phases, which may result in the destruction of the motor. Operation Voltage loss in at least one phase or voltage asymmetry between phases above the activation threshold will turn off the engine. The shutdown will occur with a delay S
