Current transformer TO-4000-5 through current transformer
F&F
PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nCurrent Transformer TO-4000-5\nF&F\nMPN : TO-4000-5\nEAN: 5902431676722\nPassage Width: 80\nHeight of passage: 163\nRated Secondary Current: 5\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nSurge CoefficientFS 5\nWith touch protectionYes\nCalibratedNo\nModelContinuous Current Transformer\nNumber of Primary Inputs1\nPassage Width [mm]80mm\nClearance Height [mm]163mm\nRated Secondary Current [A]5A\nRated Primary Current [A]4000A\nAccuracy Class0.5000\n\nProduct Description\n\nSingle phase. With an open core. 4000/5 gearbox. Power 10 VA. Current transformers convert high currents proportionally to lower values, which are adapted to the measuring ranges of control and measuring instruments.\n\nThe cable with the measured current passes through the main opening of the converter (P1/P2), which corresponds to a primary winding. The second winding terminals S1 and S2 are connect.
