GACIA Overcurrent Switch SB6L C 1P 16A 6kA AC

Name: GACIA Overcurrent Switch SB6L C 1P 16A 6kA AC
Brand: VCX

VCX

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nMiniature circuit breaker 1P C 16A 6kA AC / SB6L-1P-16C /T2UK\nParameters:\n\n--Degree of protection (IP): IP20\n-- Voltage type: AC\n-- Frequency [Hz]: 50\n-- Tripping characteristic: C.\n-- Number of poles (total): 1\n-- Rated voltage [V]: 230\n-- Number of Poles: 1\n-- Rated current [A]: 16\n-- Rated short-circuit breaking capacity according to EN 60898 [kA]: 6\n\nTechnical data: rated current: 16A characteristics: C rated impulse resistance (1.2 / 50) Uimp: 6000 rated voltage Ue: 240/415 V rated insulation Ui: 500 V current frequency Hz: 50/60 electrical life: 6000 mechanical life : 100,000 operating position indicator: yes protection class: IP 20 storage temperature: -30 / + 70 \u00B0 C operating temperature: -30 / + 50 \u00B0 C maximum cross-section of connection wires: 25 mm2 tightening torque of connection terminals: 3Nm possibility of connecting with using comb rails: yes SB6L installation ciS
