Voltage converter 0-282.8V AC / 0-400V DC output 4-20mA 9-30V DC MAX-AV-1 /T2UK

Name: Voltage converter 0-282.8V AC / 0-400V DC output 4-20mA 9-30V DC MAX-AV-1 /T2UK
Brand: F&F

F&F

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nVoltage Converter 0-282.8V AC/0-400V DC Output 4-20mA 9-30V DC MAX-AV-1I\nF&F\nMPN : MAX-AV-1I\nEAN: 5908312595335\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nFinal value of voltage measuring range [V]400V\nModular designYes\nWith binary outputNo\nBuilt-in configuration featuresNo\nType of Analog Output4-20mA\n\nProduct Description\n\nThe AV-1I voltage converter continuously measures the input value of the voltage (AC or DC circuit). The measured voltage value is converted proportionally to the Iout DC output signal in the range of 4\u00F720 mA, which corresponds to a measuring range of 0\u00F7400 V. The voltage converter allows the measurement of the actual effective value (TrueRMS) of the DC and AC voltage with an amplitude of no more than 400 V (corresponds to approximately 285 V of the effective value of the undisturbed sine voltage).\n\nThe signal output of the m.
