Bar Compact Limit Switch Box Dpdt Micro Switch 4-250V(Ac/Dc)/5A

Name: Bar Compact Limit Switch Box Dpdt Micro Switch 4-250V(Ac/Dc)/5A
Brand: Bar

Bar

This limit switch box checks the end positions for pneumatic actuated quarter-turn valves. The box is mounted on top of the actuator and detects the shaft position with built-in switches. The housing is made of polyamide (PA), the cover is Lexan 143 R, the selector shaft is constructed from polyoxymethylene (POM), the seals are nitrile butadiene rubber (NBR), and there are no metal parts. Suited for temperatures between -20 and +70 °C (-4 and +158 °F). The switch box is suitable for various mounting holes patterns and utilizes a micro-switch with a 4 V - 250 V (AC/DC) / 5 A capacity.
