H-10050 Panel Meters Black And Green Background VU(DC 500uA) With Backlight
Q-BAIHE
Title\uFF1A\n\nSD-H-10050 Panel Meters Sound Measuring Instrument Black And Green Background VU (500uA/650\u03A9) DC 500uA Audio Equipment with backlight\n\nTable core structure:\n\nmagnetoelectric system (\u221A)\n\nPointer material:\n\naluminum needle\n\nColor:\n\nWhite\n\nPointer Length:\n\n54.0 (\u00B11mm)\n\nPointer Width:\n\n0.4 (\u00B11mm)\n\nPointer deflection direction:\n\ndeflection clockwise from left to right.\n\nCover material:\n\nAcrylic (PMMA)\n\nLower cover material:\n\nAcrylic (PMMA)\n\nNameplate material:\n\nPC\n\nMagnet:\n\nhigh stability 8 type magnet\n\nMeter use position:\n\nVertical use\n\nInternal DC impedance of the meter head:\n\n650\u03A9\u00B110%\n\nFriction error:\n\n\u00B11mm\n\nBalance error:\n\n\u00B11.5mm\n\nRelative error:\n\n\u00B15%\n\nDamping time:\n\n2-3 seconds\n\nInsulation strength:\n\nabove 50M\u03A9\n Calibration value:\n \u00B12.0%\n\nLight bulb:\n\nWith internal light bulb\n\nPackage:\n\n1*SD-H-10050 Black And Green Bottom Meter :
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
17,35 GBP | Go to shop |
