High Power 355nm UV Pulse Laser Power Laser Module 20mW Can Couple Fiber Output
Q-BAIHE
Title\uFF1A\n\nHigh Power 355nm UV Pulse Laser Power Laser Module 20mW 50mW 100mW Can Couple Fiber Output\n\nWavelength:\n\n355\u00B11nm\n\nOutput Power:\n\n20mW\n\nSpatial Mode:\n\nNear TEM00\n\nOperation Mode:\n\nPulsed Laser\n\nBeam Diameter:\n\n2mm\n\nSingle Pulse Energy:\n\n1-10uJ\n\nPulse Width:\n\n5-20ns\n\nPeak Power:\n\n100W~2KW\n\nRepeat Rate:\n\n1~10KHZ\n\nPolarization:\n\n\uFF1E50:1\n\nBeam Spot Shape:\n\nCircular,Aspect Ratio <1.1:1\n\nPointing Stability:\n\n<0.05mrad\n\nBeam Divergence Angle:\n\n<1.5mrad\n\nBeam High:\n\n45mm\n\nPower Stability:\n\n<5% per4 hrs\n\nTemperature Stabilizing:\n\nTEC\n\nWarm Up Time:\n\n<5minute\n\nOperating Temperature:\n\n20-30\u2103\n\nStorage Temperature:\n\n10-50\u2103\n\nMTTF:\n\n10000hrs\n\nLaser size:\n\n211*88*74mm\n \n \n\nSupporting power supply:\n\nA: OEM type 100*70*55MM \nAC/DC PSU: 85-265V 50/60Hz input\n\nC:Lab Adjustable type: \n178*197*84mm\n\nFe:
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
8.345,00 GBP | Go to shop |
