6M Cable Float Switch Water Level Controller For Water Tank Premium
Feature: \n 1. The shell is made of environmental ABS material, non-toxic and corrosion resistant.\n2. The three wire leads adopts 0.75mm pure copper for superior electric conductivity.\n3. Stable and reliable performance, will not cause misoperation due to liquid level fluctuations.\n4. Widely used for water supply, drainage and liquid level automatic control of septic tank, water tower, water tank and water pool.\n5. Simple installation, low cost, long service life. \n\nSpecification: \n\nItem Type: Liquid Level Float Switch\nModel: KEY-6\nMaterial: ABS\nWorking Pressure: 1MPa\nWorking Voltage: 0-250V\nWorking Current: 8A\nWorking Temperature: -10~+80\u00B0C\nMaximum Temperature Resistance: 80\u00B0C\nMedia Specific Gravity: 0.7\nCable Length: 6m\nContact Capacity: 10A AC220V (Resistive)\nContact Form: 1NO, 1NC\n\nInstallation Instructions:\nWater Supply System\nUse black wire and blue wire:\nWhen the float ball is in the lower water level, the contact is on state.\nWhen the float:
