Solda-Met 5LS Comsol 3 mm dia solid wire x 12"" long

Name: Solda-Met 5LS Comsol 3 mm dia solid wire x 12"" long
Brand: V B C

V B C

Comsol\u2122 Solda -Met 5LS is a high melting point (296\u00B0C) silver-tin-lead soft solder. It can be supplied as a solid wire, as a flux\ncored wire with rosin, synthetic resin or acid type fluxes and as a specially formulated solder paste.\nThe principal characteristic of Comsol\u2122 is that it offers an improvement in creep resistance in comparison with standard tin-lead\ntype soft solders, both at normal and at elevated temperatures. For example, at 150\u00B0C a 50-50 tin-lead solder (JM5050) will fail\nunder a load of 0.7 N/mm\u00B2 in approximately 10 hours. Comsol\u2122, however, shows no creep at the same temperature. Tests\nundertaken by Johnson Matthey show that at greater loads of 1.7 and 3.5 N/mm\u00B2 Comsol\u2122 takes 1 year and 250 hours\nrespectively to fail. The high melting point of this solder also makes it useful in step soldering operations.\nDue to its tin content Comsol\u2122 shows improved wetting and flow on copper and copper alloys compared with silver-l;
