4"" / 100MM TILTING ROTARY TABLE WITH 3 SLOTS AND 2MT CENTRE BORE RDGTOOLS

Name: 4"" / 100MM TILTING ROTARY TABLE WITH 3 SLOTS AND 2MT CENTRE BORE RDGTOOLS
Brand: RDGTOOLS

RDGTOOLS

SMALL TILTING ROTARY TABLE,UNIT HAS A 2 MORSE TAPER IN THE CENTRE FOR EASY CENTRE LOCATION.BASE IS 145MM X 126MM WITH TWO 10MM MOUNTING HOLES SEPERATED BY 110MM,STANDS 66MM TALL (IN FLAT POSITION),TABLE DIAMETER 100MM, WEIGHT 4.9KG. TABLE IS GRADUATED 0-360 DEGREES IN 5 DEGREE DIVISIONS,WINDING HANDLE IS GRADUATED 0-10 DEGREES IN 5 MINUTE DIVISIONS,CAN BE DISENGAGED FOR RAPID ROTATION OF TABLE,TABLE SURFACE HAS THREE RADIAL T-SLOTS 5/16\"" WIDE,TILTS UP TO 90 DEGREES WITH A SCALE MARKED IN 1 DEGREE GRADUATIONS,UNIT WELL SUITED FOR MODEL ENGINEERING APPLICATIONS,SMALL ENOUGH TO BE MOUNTED ON SMALL MILLS OR ON A LATHE VERTICAL SLIDE OR CROSS SLIDE.PLEASE CONTACT US FOR ANY FURTHER INFORMATION\nWe are stockists of thousands of engineering tools and brands including Presto,\n Proxxon, Kreg, Tormek, Titebond, Gorilla,\n Veritas,\nEclipse, Molyslip, Moore & Wright, Britool, Facom and more
