NAIM NAP250 Amplifier Diy Assembled Class AB Power Amplifier Two Channel AMP

Name: NAIM NAP250 Amplifier Diy Assembled Class AB Power Amplifier Two Channel AMP
Brand: LJM

LJM

NAIM NAP250 Amplifier Diy Kits Class AB HI-FI Power Amplifier Two Channel AMPNotice:This is just diy kits for professionals.You have to assemble it by yourself.Thank you!~\n\nParameters\nPCB size: 67.5x48mm\nPower supply voltage DC + - 15V to DC + - 40V.\nOutput power = RMS 80W 8R (DC + - 40V)\nQuiescent Current Recommended: Voltage at both ends of the cement resistor = 1.5 MV-3MV\nThe current is about 10-20 MA.\nTHD + N = 0.001% -0.03% (20HZ-20KHZ 5W-30W 8OHM Audio Precision 2 TEST)\nFrequency response: 20HZ -0.04DB, 20KHZ -0.34 DB\n 15HZ -0.05DB, 30K HZ -52DB.\nNAIM NAP250 MOD is base on the famous NAIM NAP250, Better performance than NAIM NAP140 /200\uFF0C and the price is cheaper.\nNAP250 MOD using MINI circuit board design, reducing the length of PCB wiring.\nWhile also reducing the impact of PCB wiring resistance.\nPCB copper wire shorter, the smaller the resistance, the perford
