2 Positions Changeover Switch Stable IP10 Shell For Electrical Equipment

2 Positions Changeover Switch Stable IP10 Shell For Electrical Equipment

Feature: \n 1. Silver alloy contacts, good electrical conductivity make the switch work more stable.\n2. Adopts PC flame retardant material, high temperature resistance, good insulation performance, not easy to age.\n3. Fine workmanship, small size, 2\u2011position transfer switch with handle for flexible operation.\n4. In electrical equipment, it is mostly used to turn on and off circuits infrequently.\n5. IP10 shell protection level, stable operation, convenient and quick installation. \n\nSpecification: \n\nItem Type: Changeover Switch\nMaterial: PC+ Silver Alloy + Copper\nInstallation Board Thickness: Approx. 1-7mm / 0.04-0.3in\n\nGear Position: 0-\u2160\nReset Method: Positioning Type\nRated Voltage (Ue): 380/10A\nRated Insulation Voltage (Ui): 660V\nConventional Heating Current (Ith): 10A\nRated Impulse Withstand Voltage (Uimp): 4kV\nMechanical Life: 1,000, 000 Times\nOperating Frequency: 300 Times/Hour\nShell Protection Level: IP10\nApplication: Can be used as circuit control :
