R223C16 Relay Module 16-Channel Smart Control For Automation Excellent
Feature: \n 1. 16-channel relay module, multi-channel control.\n2. RS232 DB9 female interface, convenient and practical.\n3. Open, close, jog, self-lock, interlock, delay, all open, all close 8 working modes (8-byte instruction no delay mode).\n4. AT command and 8-byte command. The two commands are automatically recognized without switching. The maximum delay under the AT command is 9999 seconds.\n5. Maximum Load: 10A / 250VAC, 10A / 125VAC, 10A / 30VDC, 10A / 28VDC, 10A / 12VDC \n\nSpecification: \nItem Type: 16-Channel Relay Board\nPower Supply: DC 12V power supply (voltage range 9-13V)\nStandby Current: 18MA\nInterface: RS232 DB9 female interface\n8 Working Modes (8-byte Instruction Without Delay Mode): Open, close, jog, self-lock, interlock, delay, all open, all close\nTwo Types Of Instructions: AT and 8-byte instructions. The two types of instructions are automatically recognized without switching.\nMaximum delay under AT command is 9999 seconds\nSize: Approx. 172 x 65 x 19mm / :
