Finder 10A Step Relay 24VAC SPST-NO & SPST-NC

Name: Finder 10A Step Relay 24VAC SPST-NO & SPST-NC
Brand: Finder

Finder

--\nOur eBay Store\n\nPlease note: This item has a longer lead time for dispatch then normal as it's a non-stocked item that is ordered in, please see the estimated delivery date by eBay. We will of course ship the item sooner if possible.\n\nFinder 26.03.8.024.0000 10A Step Relay 24VAC SPST-NO & SPST-NC\n\nProduct Details\n\nThe Finder 26.03.8.024.0000 is a 10A Step Relay Module from the 26 series. This 24V relay has been designed for panel mounting. The relay is 31.5 wide and 28.5 high making it compact for recessed boxes or on chassis. The relay contact is 1NO+1NC (SPST-NO+SPST-NC) manufactured from a Cadmium free material. \n\n--Operating voltage: 24V AC\n--Switching capacity: Max(AC1) 2500VA/(AC15, 230V) 500VA\n--Switching voltage: Max 400V/AC/ 220V DC\n--Switching current: 10A\n--Protection type: IP20\n--Contact material: AgNi\n--Max. permanent current: (AC1) 10A/250(V/AC) 450\n--Contact type: 1 NO+1NC (SPST-NO+SPST-NC)\n--Switch-on current: Max 20A\n--Switching sequence: S;
