Surge Limiter Type T3 3kA 1/1.5kV 230V 7P.37.8.275.1003

Name: Surge Limiter Type T3 3kA 1/1.5kV 230V 7P.37.8.275.1003
Brand: FINDER

FINDER

PatKor\nProfessional industrial components\n\neBay offer\n\nShips from Poland\nTechnical Support\n\nSurge limiter type T3 3kA 1/1.5kV 230V AC, load up to 16A 7P.37.8.275.1003\nFINDER\nMPN : 7P.37.8.275.1003\nEAN: 8012823388427\nMaximum continuous operating voltage AC: 275\nRated Discharge Current (8/20) (L+N-PE): 3\nRated Discharge Current (8/20) (L-N): 3\n\nPrice per 1 pc\nTechnical parameters\nParametersValue\nMaximum continuous operating voltage AC [V]275V\nType 3Yes\nWith contact for remote signalingYes\nMounting Type35mm DIN Mounting Rail\nRated Discharge Current (8/20) (L+N-PE) [kA]3 kA\nRated Discharge Current (8/20) (L-N) [kA]3 kA\nNumber of Poles1\nProtection level L-PE/N-PE [kV]1,5000 kV\nProtection level L-N [kV]1 kV\nRated Current [A]16A\nRated Voltage AC [V]230V\nRigid wire cross section (single wire, multi wire) [mm2] for6mm\u00B2\nRigid wire cross section (single wire, multi wire) [mm2] from0.5 mm\u00B2\nConnection cable cross section (flexible, multi-wire) [mm2] to4mm.
