Star-delta system 18.5kW at 400VAC 35A, control 230VAC BFA02570230 /T2UK

Name: Star-delta system 18.5kW at 400VAC 35A, control 230VAC BFA02570230 /T2UK
Brand: LOVATO

LOVATO

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nStar-delta system 18.5kW at 400VAC 35A, control 230VAC BFA02570230 /T2UK\nParameters:\n\n--CN: 8537109800\n-- PKWiU: 27/12/31/0\n-- Rated control voltage Us for AC 50 Hz [V]: 230\n-- Rated operating current Ie at AC-3, 400 V [A]: 35\n-- Rated operating power at AC-3, 400 V [kW]: 18.5000\n-- Rated control voltage Us for AC 60 Hz [V]: 230\n-- Main circuit connection type: Screw connection\n-- Type of control voltage: AC\n\nStar-delta starter, without housing, starting time up to 12 seconds and maximum 30 operations per hour. The starter includes 3 contactors with auxiliary contacts, a time relay for this type of starters - TMST type and connecting bridges. Attention! The thermal relay must be installed separately. The thermal relay is selected based on 58% of the motor rated current (Ie). Example: Ie=100A; 58% Ie=58A. Range based on selection: 46...65A. During startup, the relay must be set to 58A.\n\n(S
