Altecnic ERES 15mm/22mm Pressure Reducing Valve with GaugeER-PRV1522

Name: Altecnic ERES 15mm/22mm Pressure Reducing Valve with GaugeER-PRV1522
Brand: ERES

ERES

\nPRESSURE REDUCING VALVE WITH GAUGE 15/22MM \nMain body has 22mm Compression on both ends but you have included in the box 2 reducers to take it to 15mm \nPRESSURE REDUCING VALVES ARE INSTALLED IN WATER SYSTEMS TO REDUCE AND STABILISE INLET PRESSURES FROM MAINS WATER SUPPLIES OR BOOSTED WATER SYSTEMS. \nTHIS PRV CAN BE INSTALLED ON HOT AND COLD SUPPLIES TO PREVENT EXCESSIVE PRESSURE AT WATER OUTLETS SUCH AS TAPS AND SHOWERS. \n \n-- DESIGNED FOR DOMESTIC AND SEMI COMMERCIAL APPLICATIONS \n-- MAXIMUM WORKING PRESSURE AT INLET: 6 BAR \n-- MINIMUM OUTLET PRESSURE: 1 BAR \n-- MAXIMUM WORKING TEMPERATURE: 65DEG \n-- OUTLET ADJUSTMENT RANGE 1-6 BAR \n-- FACTORY SETTING: 3 BAR \n-- PRESSURE GAUGE CONNECTION 1/4\"" BSP \n-- PRESSURE GAUGE READING: 0-10 BAR - 150PSI \n-- DZR BRASS BODY \nThese pressure reducing valves have a specially shaped diaphragm to give accurate pressure regulation in response to changes in downstream pressure. \nThe larger outlet chamber creates a low exit ;
