8 Channel DVR Tribrido HDCVI/Analog/iP Dahua hcvr5108h-s2

Name: 8 Channel DVR Tribrido HDCVI/Analog/iP Dahua hcvr5108h-s2
Brand: Dahua

Dahua

Main CPU System: Built-in CPU Built-in Operating System: Linux Video and Audio 8/16 Channel Analog Camera Input, BNC HDCVI, 5MP Camera, 4MP Camera, 1080P @ 25/30fps, 720P @ 50/60fps, 720P @ 25/30fps, AHD 5MP Camera, 4MP 1080P @ 25/30fps, 720P @ 25/30P @ 30P FPS, TVI. 5MP camera, 4MP 1080P at 25/30fps 720P at 25/30fps CVBS PAL/NTSC camera, 8+4/16+8CH IP camera input, each channel up to 6MP audio in/out 1/1, RCA. H Compression Recording 265+/H.265/H.264+/H.264 Resolution 5m-n, 4m-n, 1080p, 1080N, 720p, 960H, D1, CIF Main stream recording speed: 1st and 2nd channel 5m-n (1~10fps), other channels 4m-n/1080p (1~15fps); 1080N/720p/960H/D1/CIF (1~25/30fps) Secondary flow: D1/CIF (1~15fps) Bit Rate: 32Kbps ~ 6144Kbps per channel Display interface 1 HDMI, 1 VGA. HDMI Resolution: 8CH 1920×1080, 1280×1024, 1280×720 16 HP: 3840 x 2160, 2560 x 1440, 1920 × 1080, 1280 × 1024, 1280 × 720. VGA: 1920×1080, 1280×1024, 1280×720 Multi-screen display When IP extension mode is not enabled: 8CH:1/4/8/9 16CH 1/4/8/9/16 When IP extension mode is turned on: 8CH:1/4/8/9/16 16CH :1/4/8/9/16/25 OSD camera title, time, video loss, camera block. Video detection and alarm, event trigger, video recording, PTZ, tower, video push, email, FTP, snapshot, buzzer and screen suggestions. Motion Detection Video Detection, MD Zones: 396 (22×18), Lose Video, Bad Handling and Diagnosis Input Alarm N/A Relay N/A Output, Manufacturer: Dahua
