X-Axis Manual Displacement Station Optical Sliding Table Linear Stage Platform
X-Axis Manual Displacement Station Optical Sliding Table Manual Linear Stage Platform 75mm PT-SD103P\n\nFeatures:\nRail for the dovetail, carrying large\nDisplacement adjustment using bevel gear, driving force\nLarge handwheel on both sides, rotating flexible light, hand wheel can be extended according to user needs\nCursor readings, adjust the quantitative\nTable and base distribution hole standard mounting holes for easy installation and combination\nCan be composed of multi-dimensional adjustment frame or multi-dimensional adjustment and other products\n\nSpecifications:\nModel: PT-SD103P\nMaterial: duralumin\nSurface treatment: anodized black\nTable size: 110mm\u00D765mm\nDriving mode: bevel gear\nDrive position: central drive\nTravel: 75mm\nMinimum scale: 0.02\nMinimum adjustment: 10\u03BC\nGuide form: launch dovetail vice\nBearing: 20kg\nStraightness: 30\u03BC\nTable parallelism: 50\u03BC\nMotion parallelism: 40\u03BC\nWeight: 0.85kg
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
169,99 GBP | Go to shop |
