The Stripline Circulator – Theory and Practice Helszajn Hardback Wiley–Blackwell

The Stripline CirculatorTheory and Practice\nAuthor(s): Joseph Helszajn\nFormat: Hardback\nPublisher: John Wiley & Sons Inc, United States\nImprint: Wiley-IEEE Press\nISBN-13: 9780470258781, 978-0470258781\nSynopsis\nStripline circulator theory and applications from the world's foremost authority The stripline junction circulator is a unique three-port non-reciprocal microwave junction used to connect a single antenna to both a transmitter and a receiver. Its operation relies on the interaction between an electron spin in a suitably magnetized insulator with an alternating radio frequency magnetic field. In its simplest form, it consists of a microwave planar gyromagnetic resonator symmetrically coupled by three transmission lines.\n\n This book explores the magnetic interaction involved in the stripline circulator's operation, the nature of the microwave resonator shape, and the network problem that arises in coupling the microwave resonator to the microwave circuit. The stripli.
