STEPPERONLINE 1 Axis Nema 23 Stepper Motor 3Nm 4.2A 113mm &Driver DM542T CNC Kit

Name: STEPPERONLINE 1 Axis Nema 23 Stepper Motor 3Nm 4.2A 113mm &Driver DM542T CNC Kit
Brand: StepperOnline

StepperOnline

--\n--\n--\n--\n--\n--\n\nThis CNC kit included:\n\n--1 x DM542T: Digital Stepper Driver 1.0-4.2A 20-50VDC for Nema 17, 23, 24 Stepper Motor\n\n--1 x 23HS45-4204S: Nema 23 Bipolar 3Nm(425oz.in) 4.2A 57x57x114mm 4 Wires Stepper Motor CNC\n\n--1 x LRS-150-36: MEANWELL 154.8W 36VDC 4.3A 115/230VAC Enclosed Switching Power Supply\n\nMotor Specification\n\n--Manufacturer Part Number: 23HS45-4204S\n\n--Motor Type: Bipolar Stepper\n\n--Step Angle: 1.8deg\n\n--Holding Torque: 3.0Nm(425oz.in)\n\n--Rated Current/phase: 4.2A\n\n--Phase Resistance: 0.9ohms\n\n--Inductance: 3.8mH\u00B120%(1KHz)\n\n--Frame Size: 57 x 57mm\n\n--Body Length: 113mm\n\n--Shaft Diameter: \u03A610mm\n\n--Shaft Length: 24mm\n\n--D-cut Length: 20mm\n\n--Number of Leads: 4\n\n--Lead Length: 400mm\n\nConnection\n\nA+\n\nA-\n\nB+\n\nB-\n\nBlack\n\nGreen\n\nRed\n\nBlue\n\nDriver Specification\n\nPower Specification\n\n--36V DC 4.3A output\n\n--AC input voltage range: 85 ~ 132VAC\n\n--Rated power: 154.8W\n\n--AC input range se;
