STEPPERONLINE Nema 17 Pancake Stepper Motor 26Ncm 30mm 3D Printer Extruder
STEPPPERONLINE
--\n--\n--\n--\n--\nElectrical Specification\n\n--Manufacturer Part Number: 17HE12-1204S\n\n--Motor Type: Bipolar Stepper\n\n--Step Angle: 1.8deg\n\n--Holding Torque: 26Ncm(36.82oz.in)\n\n--Rated Current/phase: 1.2A\n\n--Phase Resistance: 2.5ohms\n\n--Inductance: 3.3mH\u00B120%(1KHz)\n\n--Insulation Class: B 130\u00B0C[266\u00B0F]\n\nPhysical Specification\n\n--Frame Size: 42 x 42mm\n\n--Body Length: 30mm\n\n--Shaft Diameter: \u03A65mm\n\n--Shaft Length: 22mm\n\n--D-cut Length: 16mm\n\n--Lead Length: 1000mm\n\nConnection\n\nA+\n\nA-\n\nB+\n\nB-\n\nBlack\n\nBlue\n\nGreen\n\nRed\n\n \nDimensions
Compare prices (3 shops)
| shop | Price | Action |
|---|---|---|
|
9,67 GBP | Go to shop |
|
|
9,99 GBP | Go to shop |
|
|
9,99 GBP | Go to shop |
