Pimoroni Servo 2040 18 Channel Servo Controller Board

Name: Pimoroni Servo 2040 18 Channel Servo Controller Board
Brand: PIMORONI

PIMORONI

The Servo 2040 is a neat standalone servo controller board built around the RP2040 microcontroller chip and equipped with pre-soldered headers for connecting up to eighteen 3-pin hobby servos, making it the ideal core for any number of robotics projects! Powered by the RP2040 chip and compatible with C++, MicroPython and CircuitPython Dual core ARM Cortex M0+ processor running at up to 133MHz 264kB SRAM & 2MB QSPI flash with XiP support Pre-soldered 3-pin header connectors for up to 18 servos Supports servos up to 5V as standard or higher voltage servos up to 11V by cutting the trace and providing separate power Integrated voltage and current monitoring features Six addressable LEDs for visual feedback Pin headers for connecting up to six analogue sensors QW/ST connector for Qwiic/STEMMA QT breakouts Physical Reset and BOOT buttons Note: To run servos with a voltage higher than 5V, you-ll need to cut the -Separate USB and Ext. Power- trace on the back of the board to prevent the RP2040 being damaged by the increased voltage.
