Hager ADA140U - 40a 30mA Type B Single Pole Class A RCBO Used

Name: Hager ADA140U - 40a 30mA Type B Single Pole Class A RCBO Used
Brand: Hager

Hager

Hager ADA140U - 40a 30mA Type B Single Pole Class A RCBO\n\nHager Part Code: ADA140U\n\nProduct Code: 106396\n\nCompact protection devices which combine the overcurrent functions of an MCB with the earth fault functions of an RCCB in a single unit.\n\nA range of sensitivity and current ratings are available for use in commercial and domestic installations.\n\nTechnical Data\n\nClass A Device\n\nClass A RCBOs and RCDs are not sensitive to impulsive currents up to a peak of 250 A (8/20 wave form). They are particularly suitable for protecting systems in which the user equipment has electronic devices for rectifying the current or phase cutting adjustment of a physical quantity (speed, temperature, light intensity etc.) supplied directly by the mains without the insertion of transformers and insulated in class I (class II is, by definition, free of faults to earth).These devices may generate a pulsating fault current with DC components which the A type RCD can recognize.\n\nClass A devi.
