OTL35-2 connector, blue 2xAl / Cu 2,5-35mm2 1000V Universal clamp MAA2035 /T2UK

Name: OTL35-2 connector, blue 2xAl / Cu 2,5-35mm2 1000V Universal clamp MAA2035 /T2UK
Brand: MOREK

MOREK

Application: This distribution block is suitable for connecting aluminium and copper conductors; number of poles: 1; design: 4 x Al/Cu 2.5 - 35 mm²; input/output: 2/2; cross section: 2.5 to 35 mm² Rated voltage: 1000V AC/DC; rated current: 2x Al - 120 A, 2x Cu - 135 A; torque screws: 3 Nm (2.5 - 16 mm2), 6 Nm (25 -35 mm²) Mounting type: DIN rail or mounting plate, Allen key size 4; material: body - polyamide 66, conductive parts - aluminium tin-plated, screw - aluminium tin-plated Colour: blue; weight: 44g; protection class: IP20; operating temperature: from -25°C to +80°C; burning behaviour: UL 94 V-0 Type: OTL 35-2 Halogen-free. Standard references/approval: EN 61238-1, EN 60947-7-1, EN 60998-2-1, CE
