Aco Channel Drain Stainless Steel Perforated Grate 1000Mm - Modular 125

Name: Aco Channel Drain Stainless Steel Perforated Grate 1000Mm - Modular 125
Brand: ACO

ACO

The ACO Modular 125 Stainless Steel Linear Drainage System is an improved development of the Modular Channel system. It offers excellent performance, high durability, and flexibility, suited for most applications. The system, including a stainless steel perforated locked channel drain grate with a sleek pickled finish, is available in different lengths. Its dimensions are 1000mm in length, 123mm in width, and 20mm in depth, weighing 3.2kg. It has a C250 load class, capable of withstanding 25 tonnes with a PVC infill. CE marked, it meets BS EN 1433 standards for drainage channels in vehicular and pedestrian areas, ensuring load-bearing capacity, water tightness, and durability. The Modular 125 includes varied channels, vee-bottom profiles for enhanced flow, and vertical or horizontal gully options. The system also offers gratings with A15 to C250 loading classes and optional grating security locks. It is stocked in Grade 304 stainless steel, with 316 grade available to order.. Channel Drain Stainless Steel Perforated Grate 1000mm -ACO Modular 125
