Aco Channel Drain Stainless Steel Perforated Grate 500Mm - Modular 125

Name: Aco Channel Drain Stainless Steel Perforated Grate 500Mm - Modular 125
Brand: ACO

ACO

The ACO Building Drainage Modular 125 is a stainless steel linear drainage system, improved upon its predecessor, the Modular Channel system. It's crafted with a sleek perforated design and pickled finish, making it durable and long-lasting. Dimensions are 500m in length, 123mm in width, and 20mm in depth, weighing 3.2kg. It boasts a C250 load rating, withstanding up to 25 tonnes, and requires a PVC infill. Modular 125 is CE marked, meeting BS EN 1433 standards for load-bearing capacity, watertightness, and durability. The system includes a range of sloping invert and constant-depth channels, vee-bottomed profiles for enhanced flow at low rates, and various gratings with loading class A15 to C250. It offers both vertical and horizontal gully options, and optional grating security locks. Made in Grade 304 stainless steel, but also available in Grade 316 by order. This flexible, high-performance system is ideal for vehicular and pedestrian areas.. Channel Drain Stainless Steel Perforated Grate 500mm - ACO Modular 125
