Ener-J Easy To Connect Emergency Pack For T561 from B&Q

Ener-J

Retrofit your ENER‑J T561 LED Bulkhead into emergency-ready lighting with this plug-and-play emergency module (T564). Designed for simplicity and safety, it activates automatically during power cuts, delivering up to 3 hours of maintained light at 1 W. With built-in LiFePO₄ battery, smart diagnostics, and manual/auto test support, it’s ideal for corridors, stairwells, and utility spaces where reliability matters most. Simple Plug‑and‑Play Installation – Installs directly into ENER‑J T561 bulkhead, converting it into emergency lighting without rewiring. Reliable 3-Hour Backup – Provides 1 W emergency output to connected LED load, staying lit up to 3 hours during power outages. Low Standby Power Mode – Consumes <3 W in standby; draws <0.2 W in low-power idle mode for energy efficiency. Smart Battery Management – Charges up to 200 mA; fully charges within 24 hours; includes LiFePO₄ 3.2 V 1800 mAh battery with 3-year warranty and over-current, over-discharge, and surge protection. Multiple Safety Features – Green LED indicates charging; automatically runs diagnostics and supports both manual and auto-test modes. Technical Specifications SpecificationDetailsModel / SKUEmergency Module – T564Rated Input Voltage220–240 VAC, 50/60 HzMax Input Current0.06 A @ 230 VACInrush Current30 A (cold start, 100 µs pulse)Power Factor≥ 0.5 @ 230 VACStandby Power Consumption< 3 WBattery Charging Current (Max)200 mABattery Charging TimeUp to 24 hoursEmergency Output Power1 WEmergency DurationUp to 3 hoursOutput Current (Normal / Emergency)100–15 mA / 20–5 mAOutput Voltage Range10–60 V DC (Normal); 50–180 V DC (Emergency)Battery TypeLiFePO₄ 3.2 V, 1800 mAhBattery Warranty3 yearsDriver RequirementsSurge current ≤ 8 A; Input ≤ 3 A; Output ≤ 2 ACharging IndicatorGreen LED ON = charging; OFF = faultTest ModeManual or Auto Test selectableOperating Temperature–25 °C to +60 °CStorage Temperature–40 °C to +80 °CRelative Humidity≤ 85 %IP RatingIP20 (when installed within bulkhead).
