TP-150-5 current transformer /T2UK

Name: TP-150-5 current transformer /T2UK
Brand: F&F

F&F

Welcome to the Patkor store auction\nIn this auction we offer:\n\n1 Pcs, Brand New\nTP-150-5 current transformer /T2UK\nParameters:\n\n--CN: 85043129\n-- PKWiU: 27/11/42.0\n\n3-phase. With a closed core. Gear 150/5. Power 2.5 VA. The 3-phase current transformer (3 in 1) is used for indirect measurements of three-phase currents. Its design allows for installation directly on the outputs of power switches (ABB Isomax series, Merlin Gerin NS series and similar), saving installation time and space in the switchgear. Operation The cable with the measured current passes through the main opening of the transformer (P1/P2), which is equivalent to one turn of the primary winding. The secondary winding terminals S1 and S2 are connected to the measuring circuit terminals of the control or measuring device. The ratio of currents in both windings is a constant value and is called the current ratio: IPn/ISn=N, where IPn - rated primary current; ISn - rated secondary current; N - gear ratio value. S
