Potentiometer Resistance 0-500Ohm To 0-5V 0-10V Linear Conversion Transmitter
Q-BAIHE
Title\uFF1A\nPotentiometer Resistance To Voltage 0-500Ohm To 0-5V 0-10V Linear Conversion Transmitter Module\n\nWorking voltage: \n9V ~ 17V\nInput resistance:\n0-500 ohms\n\nOutput voltage:\n0.00V ~ 5.00V/0.00V ~ 10.00V\nOutput mode:\nJ1 pad on the circuit board: open circuit (output 0.00V ~ 5.00V); short circuit (output 0.00V ~ 10.00V), the default is open circuit.\n\nDrive mode:\nNo need to drive.\nDimensions:\n(length) 26mm * (width) 23mm * (height) 10mm\n\nApplication range:\npotentiometer, resistance to voltage signal; remote data acquisition and control equipment\n\nInterface:\n12V: Power supply positive port (9V ~ 17V).\nG: Power ground interface.\nIN: Resistance input interface (0~500 ohms).\nG: Power ground interface.\nOUT: Signal output interface (0.00V ~ 5.00V /0.00V ~ 10.00V).\nG: Power ground interface.\n\nPackage:\n1*potentiometer resistance to voltage module\n\nOn 24-Sep-21 at 08:23:21 BST, seller added the following information:
