AD9834 Signal Generator Sinusoidal Triangular Square Wave Signal Module DDS
Q-BAIHE
Title\uFF1A\nAD9834 Signal Generator Module Sine Wave Triangular Wave Square Wave Signal Generator DDS Sweep Source\n\nSpecification:\nModule model: AD9834\nModule type: digital synthesis frequency source\nModule power supply: DC 5V\nModule current: 20mA (MAX) Normal driving current 15mA (TYP)\nModule communication protocol: STM32F103RCT6\nRoutine platform: STM32F103X-M3\nModule system main frequency: 75MHz (MAX)\nDAC rate bits: 10\nNumber of bits for phase accumulator: 28\nModule output interface: SMA\nModule output signals: sine wave, square wave, triangular wave\nModule output channel: 2-channel differential\nMaximum main frequency output sine wave signal range: 1Hz-30MHz\nMaximum main frequency output square wave signal range: 1Hz-10MHz\nOutput amplitude: sine wave 530mVpp (MAX) square wave 3.3Vpp\nOutput impedance: 200 ohms\nModule size: 50x50x13.6mm\n\nPackage:\n1* Amplifier Board\n\nOn 26-Sep-2023 at 02:52:22 BST, seller added the following information:
Compare prices (1 shop)
| shop | Price | Action |
|---|---|---|
|
94,61 GBP | Go to shop |
