Thermal Resistance to Voltage PT100 to 0-5V 0-10V Temperature Transmitter
XDL-PT100-TO-VOLT
Title\uFF1A\n\nThermal Resistance to Voltage PT100 to 0-5V 0-10V Temperature Transmitter Module\n\nWorking voltage:\n9V to 24V\nInput resistance:\nPt100 thermal resistance\n\nOutput voltage:\n0.00V \uFF5E 5.00V / 0.00V \uFF5E 10.00V\nTemperature measurement range:\n-100 to +500 (degrees).\n\nOutput method:\n\nS2 pad on the circuit board: open circuit (output 0.00V ~ 5.00V);\n\nshort circuit (output 0.00V ~ 10.00V), the default is open circuit. The S1 and J1 pads \nare not used.\n\nApplication:\nremote data acquisition and control equipment\n\nSize:\n(length) 26mm * (width) 23mm * (height) 10mm\n \n \n\nNote:\nWhen outputting 0.00V ~ 10.00V, the power supply voltage should be 15V.\nOutput (0.00V \uFF5E 5.00V) Resolution: 0.0083333V / \u2103 (Voltage / Celsius)\nOutput (0.00V \uFF5E 10.00V) Resolution: 0.0166666V / \u2103 (Voltage / Celsius)\n\nCalculate the measured temperature formula:\n\n(output voltage (V) / resolution) -100 \u00B0 C = measured temperature (\u00B0 C).\n\n:
