Micromotor.eu 0612S - 6V Motor 6x12mm - 6V- Single Shaft Coreless Motor

Name: Micromotor.eu 0612S - 6V Motor 6x12mm - 6V- Single Shaft Coreless Motor
Brand: Micromotor.eu

Micromotor.eu

--View our Shop\n--View our Feedback\n--Add to your Favourites\n--Ask us a QuestionProduct DetailsMicromotor.eu 0612S - 6V Motor 6x12mm - 6V- Single Shaft Coreless Motor\n\nMicromotor.eu 0612S - 6V Motor 6x12mm - 6V- Single Shaft Coreless Motor\nNo load speed (RPM,U / min) 16000\nRated speed (RPM,U / min) 13600\nNo load current 3 mA\nRated current 15mA\nStall Current 71 mA\nRated Torque 0,4 g.cm\nStall Torque 2,3 g.cm\nPower 0,05 W\nMax Power 0,09 W\n\nPlease note that this is only suitable for 6 volts and can be used in series on 12 volts with a dropper resistor (between 80 W and 180 W).\n\nCoreless Motor Information:\nGuarantee for 1 year\nDo not use with feedback controllers.\nDo not use with an analogue low frequency PWM ( Pulse Width Modulation ) Controllers. i.e. H&M Half Wave.\nDCC Frequency to at least 16 kHz (Preferred 32 kHz or higher) using the recommended correct coreless motor settings AS ADVISED by the manufacturer of the decoder.\nMaximum settings of slow speed sta.
