Micromotor.eu 0812D Coreless Motor 8mm x 12mm - double shaft 1-12V

Name: Micromotor.eu 0812D Coreless Motor 8mm x 12mm - double shaft 1-12V
Brand: Micromotor.eu

Micromotor.eu

--View our Shop\n--View our Feedback\n--Add to your Favourites\n--Ask us a QuestionProduct DetailsMicromotor.eu 0812D Coreless Motor 8mm x 12mm - double shaft 1-12V\n\nMicromotor.eu 0812D Coreless Motor 8mm x 12mm - double shaft 1-12V\n\nShaft - 1.0mm Diameter / 7.5mm Long (Each Side)\nVoltage \u2013 1-12 Volt\nNo load speed \u2013 22000 rpm\nRated speed \u2013 12000 rpm\nNoload current \u2013 20 mA\nRated current \u2013 186 mA\nStall Current \u2013 350 mA\nRated torque \u2013 8,2 g.cm\nStall torque \u2013 16,4 g.cm\nScrew Holes - None\n\nUses B0815 shaft adapters\n\nCoreless Motor Information:\nGuarantee for 1 year\nDo not use with feedback controllers.\nDo not use with an analogue low frequency PWM ( Pulse Width Modulation ) Controllers. i.e. H&M Half Wave.\nDCC Frequency to at least 16 kHz (Preferred 32 kHz or higher) using the recommended correct coreless motor settings AS ADVISED by the manufacturer of the decoder.\nMaximum settings of slow speed starting it is recommended t.
