Miniware Ds211 Mini Oscilloscope from B&Q

B&Q

MINIWARE DS211 Mini Oscilloscope is a digital storage oscilloscope compatible with a 32-bit platform with its own display and built-in battery. The built-in 8MB U disk can be connected to the computer through the Micro USB interface to exchange data. Comes with a 320x240 resolution LCD, only half the size of a mobile phone, small in size, easy to operate, and easy to use. Built-in rechargeable battery, up to 3 hours of continuous work. The highest sampling rate is 1MHz, which can meet the basic measurement of school experiments, home appliance repair, electronic engineering, and other work.Specifications:Display: 2.8″ Color TFT LCDDisplay Resolution: 320×240MCU: STM32F103VCADC: MCU internal ADCNumber of Channels: Analog channel 1 + 1 internal channelAnalog Bandwidth: 200KHzMaximum sampling rate: 1MSa / sMaximum memory depth: 8kHorizontal scanning speed: 1uS/Div~2S/Div(1-2-5sequence step)Vertical Sensitivity: 20mv/Div~10V/Div(1-2-5sequence step)Input resistance: 1MΩCoupling: DC / ACTrigger Mode: Ascend/Descend Edge Trigger ModeAuto Adjustment mode: AUTO_FITOperation waveforms: -A, RecA, A + RecASignal output: Square wave, sine wave, triangle wave, sawtoothStorage: 8MB built U diskTrigger Mode: Auto, Normal, Single, None, ScanFunction:Automatic measurement: frequency, cycle, duty, Vpp, Vram, Vavg and DC voltagePrecise vertical measurement with markersPrecise horizontal measurement with markersRising/falling edge triggerTrig level adjustable with indicatorTrig sensitivity adjustable with an indicatorHold/run featurePacking Contents:1 * DS211 Mini Oscilloscope1 * x1x10 Probe1 * USB Cable1 * User ManualPacking Specifications:Gross Weight: 255g (including package)Package Size: 170mm ✖ 98mm ✖ 40mm.
