Miniware Ds213 Mini Oscilloscope from B&Q

B&Q

MINIWARE DS213 is a compact “5-track, 4-wave line” digital storage oscilloscope designed for general electronic engineering. It uses an ARM Cortex-M3 core with an FPGA managing ADC control and data caching. The device supports four application partitions for loading different firmware versions and includes an 8MB USB flash drive for waveform storage and system upgrades. Its open-source application layer allows users to develop custom firmware.Features:Mini, lightweight, handheld designWaveform storage for clearer analysisMultiple trigger modes: edge, pulse, logicAutomatic measurements: voltage, frequency, pulse width, etc.Specifications:CPU: ARM Cortex-M3FPGA-based FIFO & controlADC: HWD9288-100Analog Channels: 2 (CH_A, CH_B)Digital Channels: 2 (CH_C, CH_D)Operation Modes: INV A/B, A+B, A–B, C&D, C|DVertical Sensitivity: 10mV–10V/div (X1), 100mV–100V/div (X10)Vertical Resolution: 8-bitMemory Depth: 4×4KCoupling: AC/DCMax Input: ±40Vpp (X1), ±400Vpp (X10)Trigger Types: edge, pulse, logicTrigger Modes: auto, normal, single, slowTrigger Sources: all channelsSignal Generator:– Square 10Hz–8MHz (20 steps, 3 Vpp)– Sine/Triangle/Sawtooth 10Hz–20MHz (11 steps, 3 Vpp)Storage: 8MB USB disk (BMP/BUF/CSV)Measurements: period, duty, peak, RMS, max/min, averageCursors: time & amplitudeDisplay: 4 wave lines with multiple channel combinationsSampling: real-time, 100MSa/sBattery: 1000mAhSize: 99.5×58.5×13.5 mmWeight: 129gCertifications: CE, FCCPackage Includes:– DS213 Mini Oscilloscope– User manualPacking:Gross weight 410gBox size 197×108×45 mm.
